Array Photos
Array photos capture the outside of the box and an aerial view of the content. Which photos are taken by the array cameras is configured in the Administration portal. Please contact your administrator or support for help with configuring the Array Photo buttons.
Position the Box for 1st Photo Array
Move the box into the 1st position for the Array
Photo based on the box size. The barcode show be shown in the Left camera
feed which will capture the photo as the ‘Front’ if the box. Please refer to Figure 6 for how to align each of the standard document storage boxes. The most common
standard document storage box is the Letter / Legal Box measuring 15” x 12” x
20” (L x W x H). Select the 1st Photo Array button to capture the
front, left, and top photos.
Position the Box for the 2nd Photo
Array
Remove the lid of the box, rotate the box 180° and realign the box with
the box position guides as shown in Figure 6. Select the 2nd Photo Array button to capture the back, right and aerial photos.
