ATA case (Steps 42 - 43)

Step 42 – Attach Front Cover

Align the Front Cover so the latches can be secured. Use your foot as a support to align the Front Cover. Once aligned, make sure there are no cables hanging that can be caught in the Front Cover Seam. Secure the latches.

Step 43 – Attach the Lid

Place the lid on the base of the ATA Case.  Make sure to align the latches. This may require jiggling the lid, so the Foam Layers are positioned inside the lid to allow for the seams to align. If the latches are too difficult to close, then the seams are not aligned. Once aligned close the four (4) latches of the lid.
